Hybrid solar wind power generation system TBB DC AC inverter charger
DC Couple and AC Couple system
Features.
-All in one unit integrating multiple functions.
-Can be applied for solar hybrid and power backup system.
-automatic temperature & voltage compensation charging.
-Equalization charging program was available for flooded and OPZS
battery.
-PWM solar charge controller with built in MC4 terminal.
-Lithium Battery charging was available.
-Designed for tropical region.
-Designed to work with weak grid.
-Extremely low status consumption power.
-ALL-IN-ONE for Solar Hybrid-system
-Compatible with majority of cheap generators in the market.
-Built in AEA
<
| Model | CK2.0L-LV | CK3.0L-LV | CK2.0L | CK3.0L | CK3.0M | CK5.0M | CK 3.0S | CK 4.0S | CK 6.0S | CK 8.0S |
| Power Assist | Yes | |||||||||
| Feed-in to grid | Yes | |||||||||
<
| Inverter | ||||||||||
| Nominal battery voltage (V) | 12 | 24 | 48 | |||||||
| Input voltage range (V) | 10.5~17 | 21-34 | 21-32 | 42~66 | 42~60 | |||||
| AC output voltage(VAC) | 110/115/120 ± 2% | 220/230/240 ± 2% | ||||||||
| AC output Frequency(Hz) | 50/60 ± 0.1% | |||||||||
| Harmonic distortion | <2% | |||||||||
| Load Power factor | 1.0 | |||||||||
| Cont. output power at 25°C (W) | 1600 | 2400 | 1600 | 2400 | 2400 | 4500 | 2400 | 3200 | 4800 | 6500 |
| Peak power (30min) (W) | 2000 | 3000 | 2000 | 3000 | 3000 | 5000 | 3000 | 4000 | 6000 | 8000 |
| Peak power (10 sec) (W) | 3200 | 4800 | 3200 | 4800 | 4800 | 6700 | 4800 | 6400 | 9600 | 13000 |
| Cont. output power at 40°C (W) | 1500 | 2200 | 1500 | 2200 | 2200 | 3600 | 2200 | 2800 | 4200 | 5600 |
| Maximum efficiency | 93% | 94% | 95% | 96% | ||||||
| Zero load power (W) | 12 | 16 | 12 | 16 | 14 | 23 | 14 | 17 | 20 | 26 |
<
| Charger | ||||||||||
| Charge voltage 'absorption' (V) | 14.4 | 28.8 | 57.6 | |||||||
| Charge voltage 'float' (V) | 13.8 | 27.6 | 55.2 | |||||||
| Battery types | AGM / GEL / OPZV / Lead-Carbon / Li-ion / Flooded | |||||||||
| Max AC charge current (A) | 100 | 150 | 100 | 150 | 80 | 150 | 40 | 55 | 80 | 110 |
| Temperature compensation | Yes | |||||||||
| General data | ||||||||||
| Main Output (AC Out1) Current (A) | 50 | 32 | 50 | 32 | 50 | |||||
| Auxiliary Output (AC Out2) Current (A) | 50 | 32 | ||||||||
| Transfer time | <2ms (<15ms in Weak AC source Mode) | |||||||||
| Remote on-off | Yes | |||||||||
| Programmable relay | 2x | |||||||||
|
|
